| Chipset | AMD X670 |
| CPU SUPPORT | Supports AMD Ryzen™ 7000 Series Desktop Processors
Socket AM5 |
| Memory | 4x DDR5, Maximum Memory Capacity 128GB
Memory Support DDR5 6600+(OC)/6400(OC)/ 6200(OC)/6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200(OC)/ 5000(OC)/ 4800(JEDEC) MHz
Max. overclocking frequency:
• 1DPC 1R Max speed up to 6600+ MHz
• 1DPC 2R Max speed up to 6000+ MHz
• 2DPC 1R Max speed up to 6400+ MHz
• 2DPC 2R Max speed up to 4000+ MHzSupports Dual-Channel mode
Supports non-ECC, un-buffered memory
Supports AMD EXPO |
| Onboard Graphics | - 1x HDMI™
- 1x DisplayPort
- Support HDMITM 2.1 FRL, maximum resolution of 4K 120Hzmsi
- 1x Display Port
- Support DP 1.4, the maximum resolution of 4K 60Hz*
- 1x Type-C DisplayPort
- Supports DisplayPort 1.4 with HBR3, maximum resolution of 4K 120Hz
|
| EXPANSION SLOT | - 1x PCI-E x16 slot
- Supports x16/x0/x4, x8/x8/x4
- PCI_E1 PCIe 5.0 supports up to x16 (From CPU)
- PCI_E2 PCIe 5.0 supports up to x8 (From CPU)
- PCI_E3 PCIe 4.0 supports up to x4 (From Chipset)
|
| Multi-GPU | Supports AMD MULTI-GPU |
| Storage | - 4x M.2 slot
- M.2_1 (From CPU) supports up to PCIe 5.0 x4, supports 2280/2260 devices
- M.2_2 (From CPU) supports up to PCIe 5.0 x4, supports 2280/2260 devices
- M.2_3 (From Chipset) supports up to PCIe 4.0 x4 , supports 22110/2280/2260 devices
- M.2_4 (From Chipset) supports up to PCIe 4.0 x4, supports 2280/2260 devices
- 6x SATA 6G port
|
| RAID | - Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices
- Supports RAID 0, RAID 1, and RAID 10 for M.2 NVMe storage devices
|
| USB | - 2x USB 2.0 (Rear)
- 4x USB 2.0 (Front)
- 4x USB 3.2 Gen1 Type A (Front)
- 6x USB 3.2 Gen2 Type A (Rear)
- 1x USB 3.2 Gen2 Type C (Rear)
- 1x USB 3.2 Gen2 Type C (Front)
- 1x USB 3.2 Gen2x2 Type C (Rear)
|
| LAN | Realtek® RTL8125BG 2.5Gbps LAN |
| WIRELESS / BLUETOOTH | AMD Wi-Fi 6E
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports 20MHz, 40MHz, 80MHz,160MHz bandwidth in 2.4GHz/ 5GHz or 6GHz bands
Supports 802.11 a/ b/ g/ n/ ac/ axSupports Bluetooth® 5.2 |
| Audio | - Realtek® ALC4080 Codec
- 7.1-Channel High Definition Audio
- Supports S/PDIF output
- Supports up to 32-Bit/384 kHz playback on front panel
|
| Internal I/O | - 1x Power Connector(ATX_PWR)
- 2x Power Connector(CPU_PWR)
- 1x CPU Fan
- 1x Pump Fan
- 5x System Fan
- 2x Front Panel (JFP)
- 1x Chassis Intrusion (JCI)
- 1x Front Audio (JAUD)
- 1x Thermal Sensor connectors(T_SEN)
- 1x Tuning Controller connector(JDASH)
- 2x Addressable V2 RGB LED connector (JARGB_V2)
- 1x RGB LED connector(JRGB)
- 4x USB 2.0
- 4x USB 3.2 Gen1 Type A
- 1x USB 3.2 Gen2 Type C
|
| LED FEATURE | - 1x EZ LED Control switch
- 4x EZ Debug LED
- 1x 2-Digit Debug Code LED
|
| BACK PANEL PORTS | - Clear CMOS Button
- Flash BIOS Button
- DisplayPort
- USB 2.0
- 2.5G LAN
- Audio Connectors
- Smart Button
- HDMI™
- USB 3.2 Gen 2 10Gbps (Type-C Display port)
- USB 3.2 Gen 2 10Gbps (Type-A)
- USB 3.2 Gen 2×2 20Gbps (Type-C)
- Wireless / Bluetooth
- S/PDIF-Out
|
| OPERATING SYSTEM | Support for Windows® 11 64-bit, Windows® 10 64-bit |
| PCB Dimension | ATX
304.8mmx243.84mm |
| Warranty | 3 Years |
| |
