| Model Number |
MCB-NR200P-WGNN-S00 |
| Series |
MasterBox Series |
| Size |
Mini ITX |
| Available Color(s) |
White |
| Materials |
Steel, Plastic, Mesh, Tempered Glass |
| Dimensions (L x W x H) |
376 x 185 x 292mm incl. Protrusions, 360 x 185 x 274mm excl. Protrusions |
| Volume (exlc. Protrusions) |
18.25L |
| Motherboard Support |
Mini DTX, Mini ITX, Max MB size: 244 x 226mm (L x H) |
| Expansion Slots |
3 |
| 5.25″ Drive Bays |
0 |
| 3.5″ Drive Bays |
1 (Max. 2) |
| 2.5″ / 3.5″ Drive Bays (combo) |
1 |
| 2.5″ Drive Bays |
2 (Max. 3) |
| I/O Panel |
2x USB 3.2 Gen 1 Type-A, 1x 3.5mm Headset Jack (Audio+Mic) |
| Pre-installed Fans – Top |
2x 120mm 650-1800RPM PWM (SickleFlow) |
| Pre-installed Fans – Front |
N/A |
| Pre-installed Fans – Rear |
N/A |
| Pre-installed Fans – Bottom |
N/A |
| Fan Support – Top |
2x 120mm |
| Fan Support – Rear |
1x 92mm |
| Fan Support – Bottom |
2x 120mm (recommended slim fans for GPUs wider than 2.5 PCI slots) |
| Fan Support – Side |
2x 120/140mm |
| Radiator Support – Top |
N/A |
| Radiator Support – Rear |
92mm (not compatible with vertical GPU installation) |
| Radiator Support – Bottom |
120mm, 240mm, (recommended for custom loops only) |
| Radiator Support – Side |
120mm, 140mm, 240mm, 280mm, (not compatible with vertical GPU installation) |
| Clearance – CPU Cooler |
76mm (GPU in vertical position), 153mm (tempered glass side panel) |
| Clearance – PSU |
130mm |
| Clearance – GFX |
L: 330mm (incl. power connector), H: 156mm (incl. power connector), W: 60mm (triple slot) |
| Dust Filters |
Top, Bottom, Left side, Right side |
| Power Supply Support |
SFX, SFX-L |
| Accessories |
1x PCIe 3.0 x16 riser cable |
| Warranty |
2 Years |
| Note |
***Features, pricing, and specifications are subject to change without notice, and items may sometimes be out of stock. |
