AMD
AMD Ryzen 7 7700X Processor with Radeon Graphics
₹26,000
Inclusive of GST
₹35,000
Save ₹9,000 (26%)
In stock· Only 1 left
1
- Socket
- AM5
- Cores
- 8
- Series
- 7000 SERIES
- Threads
- 16
- Max memory support
- 128GB
- Speed
- 4.5 GHz
- GST invoiceWith every product
- Manufacturer warrantyWe help with the RMA
- Secure paymentCard, UPI or netbanking
- Visit the storeGota, Ahmedabad
Overview
Specification
| Platform | Desktop |
|---|---|
| Market Segment | Enthusiast Desktop |
| Product Family | AMD Ryzen™ Processors |
| Product Line | AMD Ryzen™ 7 Desktop Processors |
| AMD PRO Technologies | No |
| Consumer Use | Yes |
| Regional Availability | Global |
| Former Codename | “Raphael AM5” |
| Architecture | “Zen 4” |
| of CPU Cores | 8 |
| Multithreading (SMT) | Yes |
| of Threads | 16 |
| Max. Boost Clock | Up to 5.4GHz |
| Base Clock | 4.5GHz |
| L1 Cache | 512KB |
| L2 Cache | 8MB |
| L3 Cache | 32MB |
| Default TDP | 105W |
| Processor Technology for I/O Die | TSMC 6nm FinFET |
| CPU Compute Die (CCD) Size | 71mm² |
| I/O Die (IOD) Size | 122mm² |
| Package Die Count | 2 |
| Unlocked for Overclocking | Yes |
| AMD EXPO™ Memory Overclocking Technology | Yes |
| Precision Boost Overdrive | Yes |
| Curve Optimiser Voltage Offsets | Yes |
| AMD Ryzen™ Master Support | Yes |
| CPU Socket | AM5 |
| Supporting Chipsets | A620 X670E X670 B650E B650 |
| CPU Boost Technology | Precision Boost 2 |
| Instruction Set | x86-64 |
| Supported Extensions | AES, AMD-V, AVX, AVX2, AVX512, FMA3, MMX(+), SHA, SSE, SSE2, SSE3, SSE4.1, SSE4.2, SSE4A, SSSE3, x86-64 |
| Thermal Solution (PIB) | Not included |
| Max. Operating Temperature (Tjmax) | 95°C |
| OS Support | Windows 11 – 64-Bit Edition Windows 10 – 64-Bit Edition RHEL x86 64-Bit Ubuntu x86 64-Bit |
Connectivity
| USB Type-C® Support | Yes |
|---|---|
| Native USB 3.2 Gen 2 (10Gbps) Ports | 4 |
| Native USB 3.2 Gen 1 (5Gbps) Ports | 0 |
| Native USB 2.0 (480Mbps) Ports | 1 |
| Native SATA Ports | 0 |
| Native PCIe® Lanes (Total/Usable) | 28/24 |
Additional Usable PCIe Lanes from Motherboard AMD X670E 12x Gen4 AMD X670 12x Gen4 AMD B650E 8x Gen4 AMD B650 8x Gen4
| NVMe Support | Boot, RAID0, RAID1, RAID10 |
|---|---|
| Memory Channels | 2 |
| Max. Memory | 128GB |
| System Memory Subtype | UDIMM |
| Max Memory Speed | 1x1R 5200 MT/s 1x2R 5200 MT/s 2x1R 3600 MT/s 2x2R 3600 MT/s |
| ECC Support | Yes (Requires mobo support) |
Graphics Capabilities
| Integrated Graphics | Yes |
|---|---|
| Graphics Model | AMD Radeon™ Graphics |
| Graphics Core Count | 2 |
| Graphics Frequency | 2200 MHz |
| USB Type-C® DisplayPort™ Alternate Mode | Yes |
| Product ID Boxed | 100-100000591WOF |
| Product ID Tray | 100-000000591 |
Key Features
| Supported Technologies | AMD EXPO™ Technology AMD Ryzen™ Technologies |
|---|---|
| Warranty | 3 Years |
Specifications
- Brand
- AMD
- Series
- 7000 SERIES
- Cores
- 8
- Threads
- 16
- Max memory support
- 128GB
- Socket
- AM5
- Speed
- 4.5 GHz
- Cache memory
- 40 MB
- Tdp
- 105W
- Warranty
- 3 Years
- Cpu
- RYZEN 7
- Chipset
- A620, B650, B850, X670, X870
- SKU
- 100-100000591WOF
